Most recently, Thomas Honeyman, a senior engineer at Awake Security, created a Pact developer tutorial series titled “Real World Pact”, which contains tutorials on:

The Kadena.js team has taken it upon themselves to create a step-by-step guide of the Goliath Project, including video demonstrations of the Goliath Wallet UI, summarizing a portion of Honeyman’s work, specifically with respect to the contract portion of the Goliath Project. The purpose of the step-by-step guide is to enable developers and interested individuals to start coding easily. For those interested in exploring the entire repo, please see Goliath Faucet Contract Overview and Goliath Faucet Main Contract.

The guide will provide the following :

The Goliath faucet is a simple smart contract that allows users to request KDA. Even though it’s a small contract, we’ll cover the majority of Pact’s features in the process of building it. The faucet contract is intended for use on a test network, so it will allow anyone to request funds.

We’ll implement these features in idiomatic Pact:

After following all the steps, you’ll be able to understand the contract behind the app, Goliath wallet.

Welcome to the Goliath faucet smart contract!

We’re using the Pact smart contract language. A smart contract can contain a mixture of:

A typical Pact smart contract executes some top-level setup code by defining one or more keysets and entering a namespaces. Then, it defines a module and/or interface that other modules can reference. Finally, it executes more top-level code to initialize data required by the module, such as creating new tables. Each of these steps introduces critical concepts for Pact development.

We’ll take all these steps in our smart contract. We’ll begin by exploring namespaces, keysets, interfaces, and modules. Then we’ll implement the “goliath-faucet” module and finish up by initializing some data.

Our contract begins by entering a namespace.

Modules, interfaces, and keysets in Pact must have unique names within a particular namespace. On a private blockchain you can define your own namespace or use the "root" namespace (ie. no namespace at all). On a public blockchain the root namespace is reserved for built-in contracts (like the coin contract, which we’ll see later), and on Chainweb specifically you can only define a new namespace with the approval of the Kadena team.

In short, we technically can define a namespace with (define-namespace) in our contract but, practically speaking, we can’t do this on Chainweb. So we can’t define a namespace, and we can’t use the root namespace. What are we to do?

Chainweb exposes two namespaces for public use: "free" and "user". You can define interfaces, modules, and keysets inside either of these two interfaces.

To do that, enter the namespace with the (namespace) function. #namespace

We’ll use the "free" namespace for our contract:

Now that we are inside the "free" namespace, we can begin defining keysets for use in our module.

Public-key authorization is widely used in smart contracts to ensure that only the holders of specific keys can take certain actions (such as transferring funds from their account). Pact integrates single- and multi-signature public-key authorization into smart contracts directly via the concept of keysets.

Pact has other tools for authorization as well as a whole, authorization in Pact is handled via guards or capabilities (we’ll learn about both later), and a keyset is a specific kind of guard.

So what, concretely, is a keyset? A keyset pairs a set of public keys with a predicate function. In JSON form it looks like this:

Pact will check the predicate function against the set of keys when the keyset is used as a guard. If the predicate fails then access is denied. There are a few built-in predicate functions, such as the “keys-all” function above this predicate means means that all keys in the set must have signed the transaction. You can also write your own predicate functions (for example, to authorize access according to a vote). #keysets-and-authorization

Keysets are defined via the (define-keyset) function. This function takes a name and a keyset as arguments. When evaluated, Pact will either register the keyset at the given name on Chainweb or, if the name is already registered, then it will “rotate” (ie. update) the keyset to the new value. #define-keyset

When registering a keyset in a smart contract it’s a common practice to send the keyset in the deployment transaction data instead of hardcoding it into the contract. That’s because keyset references can be rotated (ie. upgraded) once rotated, the keyset name won’t refer to the value written in the contract anymore. If you ever want to see the current value of a keyset reference, you can look it up by name by sending this code to a Chainweb node:

Let’s proceed with defining the “free.goliath-faucet-keyset” using the keyset

provided via transaction data. You can parse data from the transaction using the (read-\*) family of functions: #read-msg #read-keyset #read-string #read-integer #read-decimal

Our deployment transaction will be sent with two pieces of data:

Below, we read the Goliath faucet keyset from the transaction data and register it, but only if we are deploying (not upgrading) this contract. Once the keyset is registered, our Pact module can refer to it when guarding sensitive information. To see how to provide a keyset in transaction data please refer to the faucet.repl file and the deploy-faucet-contract.yaml file.

If reading the ‘upgrade’ field yields ‘true’, then this isn’t our initial deployment and therefore we should skip registering the keyset.

Otherwise, this is our initial deployment, so we should register the keyset. Just one more thing before we proceed: we should verify our keyset. There are multiple reasons to do this.

First, what if we have a typo in the keyset sent in the transaction data? The typo keyset will be registered and we’ll be unable to access anything guarded by it!

Second, you don’t have to define a keyset inside your smart contract. You may wish to reuse the same keyset reference in multiple contracts, and so you simply reuse the keyset reference in your contract. This can be dangerous, however. If you deploy a contract referring to a keyset but you forgot to register that keyset, then someone else can register the keyset with their keys and gain access to your guarded data. To prevent these risks it’s a best practice to enforce a keyset guard on the transaction that deploys the contract. This guard should ensure that any keysets passed to the contract were also used to sign the transaction that deploys the contract. If the enforcement fails, the deployment is aborted, and you can fix the keyset and try again. #keyset-ref-guard

So far we’ve been writing code at the top level. Code at the top level is ordinary Pact that Chainweb can execute. However, when you are defining a new smart contract, you need to organize your Pact code into interfaces and/or modules so that it can be referenced later from other contracts or via a Chainweb node’s Pact API. Chainweb will store your interfaces and modules within the namespace you’ve entered.

Interfaces and modules are both units for organizing Pact code, but they serve different purposes. An interface describes the API that a module will

implement and can supply constants and models for formal verification to aid in that implementation, but it doesn’t contain any implementations itself and cannot be executed on Chainweb. #interfaces

Interfaces purely exist as a method of abstraction. An interface can be implemented by multiple modules (that means that the module provides an implementation for every function included in the interface), so it serves as a blueprint for implementers. Also, Pact functions take a reference to module as an argument so long as the module implements a specific interface. That means you can write a function that can be used with any module that implements the given interface — a powerful form of abstraction. #module-references

We don’t use interfaces in our contract because it’s quite small and no one else is expected to provide another implementation for its API. Instead, we skip straight to the implementation: the ‘goliath-faucet’ module.

A module in Pact is the primary unit of organization for Pact code. Modules can contain functions, pacts, capabilities, tables, and other Pact code. #module

Let’s define a Pact module with the code for our faucet. To define a module we must provide a module name, a module governance function, and then the module body containing the implementation.

The ***module name*** is used to refer to the module from other modules (or in the REPL). For example, coin.transfer refers to the transfer function defined in the coin module. To refer to a module it must have been deployed to Chainweb (or loaded into the REPL). We’ll name our module goliath-faucet.

Since we’re within the free namespace, that means we can refer to our module on Chainweb with the prefix free.goliath-faucet. The **module governance function** restricts how the contract can be upgraded.

Governance functions can be a keyset reference, which means that the contract can be upgraded so long as the upgrade transaction satisfies the keyset, or they can be a “capability” defined in the module. We’ll learn a lot more about capabilities later and will use a keyset reference as our governance. #keysets-vs-governance-functions

Now, let’s implement the body of our module. We’ll begin with the two forms of metadata we can use to annotate our modules, interfaces, functions, table schemas, and other Pact code. The @doc metadata field is for documentation strings, and the @model metadata field is for formal verification. #docs-and-metadata

It’s a best practice to document interfaces, modules, functions, table schemas, and other Pact code using the @doc metadata field. We’ll do that throughout our contract, beginning with the module itself.

The second metadata type is @model. It allows us to specify properties that functions must satisfy and invariants that table schemas must satisfy. Pact, via the Z3 theorem prover, can prove that there is no possible set of variable assignments in our code that will violate the given property or invariant. Or, if it does find a violation, it can tell us so we can fix it! #what-do-properties-and-schema-invariants-look-like

Properties (but not invariants) can be defined at the top level of the module so they can be reused in multiple functions. #defining-and-reusing-properties

We have a few functions that should never succeed unless they were called in a transaction signed by the Goliath faucet keyset. We can capture that property in a reusable definition. We’ll see examples of using this property within a function later on.

It’s useful to define constants in your interface for values that will be used in several functions, or values that other modules should be able to refer to.

Our faucet contract has a specific range of values that it will allow the per-request and per-account limits to be set to. It’s useful to capture these values in variables that our tests, module code, and other modules on Chainweb can refer to. To expose a constant value, use (defconst). #defconst

When your smart contract needs to persist some data across multiple calls to functions in the contract, it should use a table. Tables in Pact are relational databases and have a key-row structure. Keys are always strings. You can define a table with deftable. #deftable

Our smart contract needs to persist four pieces of data. First, we need to record how much KDA in total each account has requested and returned so that we know when a request would exceed the per-account limit. We also need to record the per-request and per-account limits, as they can be adjusted by the faucet account at any time.

Before we define any tables, however, we should define schemas for them. The schema for a table specifies the table columns and their data types. #defschema

The schema will be used to verify we are using the right types when reading or writing the table. For example, Pact can typecheck our module and ensure we never try to provide a string for an integer column, or try to insert a row that’s missing a column.

By convention, we use the same name for a table and its schema, except we give the schema a -schema suffix.

We’ve seen @model used to define some reusable properties at the module level. Now, let’s see how to leverage invariants (ie. formal verification for table schemas) to guarantee it is never possible for an address to exceed their account limit or return more funds than they have requested. To specify an invariant, use (invariant) and provide a predicate; the Z3 theorem prover will check that the variables used in your predicate can never have values that would fail the predicate. Not all Pact functions can be used in the predicate; you can see a list of available ones here #property-and-invariant-functions

The first invariant ensures that you can never receive more funds than your account limit. The second ensures you can never return more funds than you have received. Then, we define our four columns and their types.

Now that we have our schema we can define a table which uses it with the (deftable) function. #deftable

We’ll refer to the table by name when we need to insert, read, or update data. When our module is deployed, we’ll also need to create the table using the (create-table) function (this must be called outside the module). #create-table

Pact supplies several data-access functions for working with tables. #database

Note that these functions can only be called by functions within the module that defined the table, or in a transaction that satisfies the module governance function. Beyond these points of access, no one can read or write to tables directly.

Next, let’s explore a fundamental pair of concepts in Pact: guards and capabilities. A guard in Pact defines a rule that must be satisfied for the transaction to continue.

We’ve seen an example already: keysets are one type of guard. But there are others, such as pact guards (used to guard that transaction is executed within a certain multi-step transactions, such as (coin.transfer-crosschain) and user guards (arbitrary user-defined predicate functions).

In short, guards are pure predicate functions over the given environment, which can be enforced at any time with (enforce-guard).

A capability, on the other hand, implements fine-grained control over how a guard is deployed to grant some access to a user of the smart contract.

Capabilities in Pact are an entire system for managing user rights during the execution of a transaction. You can define a new capability with (defcap). A capability consists of a name, a list of arguments, optional metadata, and a function body that returns a boolean.

For example, an ADMIN capability might ensure that a specific keyset must be satisfied in order to take some action:

Capabilities can implement more sophisticated rules, such as orchestrating a vote to determine whether the contract can be upgraded. You can learn more about capabilities in the Pact documentation. #capabilities

There are four critical things to know about capabilities.

First, you can grant a capability to a function with (with-capability), and you can protect some sensitive code with the (require-capability) function. “Granting” a capability means that calls to (require-capability) will succeed so long as the capability is in scope. #with-capability #require-capability

Second, you can only grant a capability within the module that defined the corresponding capability. That means, for example, that protecting code with (require-capability) means that code cannot be called from outside the module, because its required capability can only be granted within the module. This is a helpful way to make particular functions private.

Third, capabilities come in two flavors: unmanaged and managed. Acquiring either will let you access code protected by (require-capability). However, unmanaged capabilities are static (they only rely on their parameters and transaction data to determine whether the capability should be granted), whereas managed capabilities can be dynamic (they additionally rely on state that can change each time the capability is requested during a given transaction). By convention, unmanaged capabilities are “granted” and managed capabilities are “installed”. You can tell that a capability is managed if it uses the @managed metadata field.

We won’t use managed capabilities in this contract, but you can learn more about them here: #signatures-and-managed-capabilities #what-are-the-semantics-of-capability-manager-functions-in-pact

Finally, signers of a Pact transaction can scope their signature to one or more capabilities in the module. This indicates that the signer has agreed to grant the specified capabilities if they are asked for via the (with-capability) function, but other capabilities should be denied.

Managed capabilities must always be scoped; unmanaged capabilities don’t always have to be scoped. When the signer signs with empty capability list, unmanaged capabilities required in the transaction will be signed.

You can see examples of scoping a signature to a capability in the faucet.repl file and in the various ‘send’ request files.

Our contract will use one capability: SET_LIMIT. It ensures that calls to change the per-request and per-account limits for a given account must be signed for by the goliath-faucet account.

The module’s SET_LIMIT capability will be a simple keyset guard. To grant this capability in a function in this module with (with-capability), the transaction that calls that function must be signed by the goliath-faucet private key, scoped to the SET_LIMIT capability.

Now for the fun part! It’s time to implement the core logic of our smart contract. Each feature of the contract will be represented by a function.

We’ll implement functions for users to request and return funds and to look up their account limits. We’ll also implement two admin-only functions to adjust an account’s limits. Along the way we’ll see how to grant capabilities, prevent invalid states, read and write tables, format strings, and more.

Our first function lets users request funds from the faucet. Specifically, we will call the (coin.transfer-create) function from the coin contract IF the requested amount is within the account limits for the receiving account. If our checks pass (the amount is valid), then we’ll transfer the funds and then update our accounts table to reflect the transfer.

We’ll use two properties to help ensure correct behavior for this function. First, the transaction should only succeed if the address requested a positive amount. Second, if the transaction succeeded, then the table at the ‘funds-requested’ column must have increased by the amount requested. The first property is a simple check, but the second uses a property-only function called (column-delta). #column-delta

Recall that due to our schema invariants we have some additional checks that verify that our table writes are always within the valid bounds of our account and request limits. But they won’t stop us from forgetting to write to the table at all, or from writing a value that’s not the exact amount the user requested. (column-delta) can ensure that for us.

Pact’s formal verification will check that your implementation satisfies the two properties above, but we still have to write the code that prevents the invalid states. To abort a transaction if it fails to meet a condition, use (enforce). #enforce

To see formal verification in action, comment out this line and re-run the REPL file.

We still need to verify that the amount is within the account’s limits. To do that, we must read the receiver’s limits from the accounts table if it exists there (ie. it has requested funds before), or assume the default limits if not.

There are a number of functions for reading and writing tables. One of the most common is (with-default-read), which is used to read a row from a table, with a fallback value in the case the row does not exist. #with-default-read

The := operator indicates that we are storing the value of the column on the left-hand side in the variable name on the right-hand side within the scope of the (with-default-read) call.

From this point on we have access to the values of the four columns associated with the receiver account in the accounts table. Let’s use them to bind a helper variable, balance, that records the difference between the total requested funds and the total returned funds.

For binding the variable, we can introduce local variables with (let). #let

This balance is what should be checked against the account limit. Now, we can finally enforce that the requested amount does not exceed the request limit.

We can also ensure that transferring the requested amount would not result in exceeding the total account limit.

With these checks satisfied, we know that the address has requested a valid amount and we process the transfer using the (coin.transfer-create) function: coin contract #L358–362

Notice that the (coin.transfer-create) function grants a capability, (coin.TRANSFER), as part of its implementation: coin contract #L377

That means that a transaction that calls this (request-funds) function must be signed by the faucet account keys, and that signature must be scoped to the (coin.TRANSFER) capability. To see examples of how to do this, please see the faucet.repl file and the request-funds.yaml request file!

If the transfer succeeded, then we should update the accounts table to indicate the user has requested more funds. If you’d like to see our formal verification in action, try “accidentally” hardcoding the funds-requested update below to a specific number in the faucet.pact file.

Our next two functions can only be called by the faucet account itself. They adjust the per-request or per-account limit for a given address. We’ll implement checks to ensure that the new limits are greater than the old limits and that the transaction executing this function was signed by the faucet account.

Once again we’ll reach for property tests to ensure our function is correct.

The first property test verifies that the faucet signed this transaction — it’s referring to the (faucet-authorized) property we defined at the module level earlier in our code.

The second property test verifies that if this transaction succeeded, then the accounts table row for this account, at the “request-limit” column, has been updated to be the value provided to this function. Similarly to (column-delta), we can use this to verify that the table is written correctly. #read

The primary way to enforce a condition in a function is the (enforce) function. However, we can also put enforcement logic into a capability. A function can only acquire that capability via (with-capability) if the enforcement checks in the capability succeed. Capabilities are the best tool to reach for when you want to pass a transaction only if it was signed with particular keys; in our case, we have a (SET_LIMIT) capability that enforces that the "free.goliath-faucet-keyset" keyset must be satisfied in order for the SET_LIMIT capability to be granted.

Since we want the (set-request-limit) to be only called by the faucet account, the SET_LIMIT capability is the perfect way to restrict access to this function. To see an example of how to sign a transaction with this capability, please refer to the faucet.repl file or the set-user-request-limit.yaml request file.

We used (with-default-read) before because we wanted to provide a fallback value in case the account had never requested funds before. This function is different: it should not be possible to update the limits for an account that hasn’t yet requested anything. (with-read) will fail the transaction if the given account does not exist in the table, and read the row otherwise. #with-read

Note that when using (with-read) it is not necessary to bind variables to every column in the table. You can just use the columns you want.

We used (write) before because we were inserting a new row into the table if the account didn’t yet exist. To update one or more columns in an existing row you can use (update). #update

Like (with-read), it’s only necessary to include the columns that you are updating, not all the columns.

The (set-account-limit) function is almost identical to the (set-request-limit) function, just targeting a different field.

Our next function is a little helper that lets users look up their account limits from our table. Remember: tables cannot be accessed outside your module for security reasons. If you want to provide access to specific data, write a function that performs the table read.

Our final function allows users to transfer funds back to the faucet account and credit it against their account limit. The property tests, enforcements, table reads and writes, and let bindings should start looking familiar!

We didn’t implement a property for this because our table invariants already verify that the funds returned can never exceed the funds requested. You can verify that removing this enforcement check will make the model checker yell at us.

Next, we transfer from the user account to the faucet account. To transfer funds from the user to the faucet account the user must have signed the transaction and scoped their signature to the (coin.TRANSFER) capability. For examples, please see the faucet.repl file and the return-funds.yaml request file.

At this point we’ve established our smart contract: we entered a namespace, defined a keyset, and implemented a module. Now it’s time to initialize data.

For a typical smart contract, that simply means creating any tables we defined in the contract. However, more complex contracts may perform other steps, such as calling functions from the module.

Tables are defined in modules, but they are created after them. This ensures that the module can be redefined (ie. upgraded) later without necessarily having to re-create the table.

Speaking of: it’s a common practice to implement the initialization step as an ‘if’ statement that differentiates between an initial deployment and an upgrade. As with our keyset definition at the beginning of the contract, this can be done by sending an “upgrade” field with a boolean value as part of the transaction data

We have completed writing a faucet contract that can be deployed on devnet. The next steps will be running a devnet on your local machine, and running the faucet application that calls the functions from the contract.

You can start by following the instructions here: https://github.com/thomashoneyman/real-world-pact/tree/main/02-goliath-wallet

The Kadena.js team hopes that this step-by-step guide was practical and helpful.
